Description
JUNHE coating machines are compatible with various materials such as zinc-aluminum micro-coatings, topcoats, sealants, and Teflon. They meet the coating and batch control requirements for automotive blind-hole fasteners and hardware components, ensuring a high finished-product yield.he system adopts low-speed mixing and high-speed centrifuging to achieve uniform coating with no dead corners, minimal liquid accumulation, and excellent consistency. It also offers advantages in safety, environmental protection, material-mixing prevention, dual-basket configuration, and low operating cost, while supporting digitalization and IoT upgrades.
Coating Equipment main body
Isolating room, coating machine, weighing loading system, distributing system, control system.
Features
1. Tiltable designed to ensure uniform coating of paint, no dead angle, no effusion.
2. More intelligent, high pass rate of production.
3. Can realize remote monitoring, it is convenient and safe to use.
4. CE certificate.
5.Modular Standardization:
Modular and standardized design with a built-in control cabinet; the entire system is preassembled for plug-and-play installation, ensuring convenient setup. Intelligent and IoT options are available for easy upgrades. Compatible with JUNHE® standard sintering furnaces without debugging.
6.High Yield Efficiency:
Adopts low-speed mixing, high-speed centrifuging, and tilting low-speed rotation to ensure uniform coating and effectively reduce liquid accumulation in blind-hole components.
7.Safe and Environmentally Friendly:
Prevents paint splashing with a fully enclosed structure and centralized exhaust collection system. Suitable for both water-based and solvent-based coatings.
8.Excellent Batch Management:
Each batch of workpieces is processed by weight according to the set parameters, with fully automatic operation, real-time monitoring, and complete data recording. The entire process runs smoothly with no risk of material jamming.
9.Flexible Module Configuration:
Optional modules include coating, loading, weighing, anti-collision, unloading, robotic handling, constant-temperature coating, coating control and inspection, exhaust treatment, and standardized wear parts. All modules are plug-and-play, improving flexibility and maintenance efficiency.
Technical Data
| Centrifugal speed |
0~320 |
r/min |
| Max tilting angle |
75 |
° |
| Max load of basket |
180 |
kg |
| Shortest production rate |
180 |
s |
| Max capacity |
3600 |
kg/h |
| Suitable workpiece weight |
≤600 |
g |
| Suitable workpiece length |
≤25 |
cm |
